connector for automobile HX75015-HX6.3K-HX35000
Certifications Approval and Compliances
UL
connector for automobile HX75015-HX6.3K-HX35000
HX75015-HX6.3K-HX35000- Automotive series connector - Zhejiang Hongxing Electric Co., Ltd. focuses on HX75015-HX6.3K-HX35000- Automotive series connector products, our company insists on HX75015-HX6.3K-HX35000- automotive series connector as the core, The market share of HX75015-HX6.3K-HX35000- automotive series connectors has gradually increased
  • Samples date :
    1-7days,Free with freight collect
  • Delivery date :
    1-7 days
  • MOQ :
    6ft-3000pcs/4ft-5000pcs
  • Packing :
    Export cartons,pallets,Express box
  • Shipping :
    By Sea,Air,TNT,FedEx
  • Payment :
    Wire Transfer
What is RoHS REACH PAHS of power cords

Inquiry
Message
Product Info
<< Back to Connector for automobile
Description

HX75015-HX6.3K-HX35000- Automotive series connector - Zhejiang Hongxing Electric Co., Ltd. focuses on HX75015-HX6.3K-HX35000- Automotive series connector products, our company insists on HX75015-HX6.3K-HX35000- automotive series connector as the core, The market share of HX75015-HX6.3K-HX35000- automotive series connectors has gradually increased

Features
The quality is good,Durable,Environmental protecti
Details

HX75015-HX6.3K-HX35000

Specifications
  • (Model): HX75015-HX6.3K-HX35000
  • (Voltage): 250V AC/DC
  • (Withstandvoltage): 800V AC/1min
  • (Amperage): 10A
  • (Contact resistance): ≤0.02Ω
  • (Insulation resistance): ≥1000MΩ
  • (Temperaturerange): 5g
  • (Color): Brass/Silver
Material
  • (Models Desc): Bareness pre insulation
  • (Material Structure): Bareness pre insulation
  • (Skin Material): Tinning/Nickel plating
  • (Conductor Material): Oxygen-free copper/Orichalcum
  • (Insulating Material): PVC PA66
  • (Plug housing): PA66 UL94V-0
  • (Receptacle housing): PA66 UL94V-0
  • (Wafer): PA66 UL94V-2(0)
  • (Terminal): Phos.bronze Tin/plated
Quality
  • (Approvals): UL
  • (Standard): JIS GB
  • (Quality System): ISO9001:2008
  • (Testing): SGS TUV
  • (Environmental): ROHS,REACH,PAHS
  • (Environmental mark): What is RoHS REACH PAHS of power cords
More and more
  • (Patent): NYC
  • (Country of Origin): Zhejiang Ningbo
Sea and air freight
connector for automobile HX75015-HX6.3K-HX35000 Sea and air freight
Free sample
connector for automobile HX75015-HX6.3K-HX35000 Free sample
PDF Support
connector for automobile HX75015-HX6.3K-HX35000.PDF Support
